Introduction

Bedrock is an imperative, statically typed systems programming language designed around simplicity, readability, and practicality.

The goal is to provide the control expected from a systems language while removing unnecessary complexity from the programming model.

Memory is managed automatically through a region-based memory model. For C interoperability an unsafe block is required.

The language intentionally avoids object-oriented programming. Programs are built using procedures, functions, structs, and modules instead of classes or inheritance.

---

---

Getting Started

Start by setting up your local development environment by installing the necessary tools according to the installation instructions.

Now to test that the installed bok compiler works, copy this code sample in a file named hello.bok

extern proc printf(...);

proc main()
    printf("Hello, World!\n");
end

Note: using libc printf until we have our own stdlib. :(

Then in your terminal run this command:

bok hello.bok --jit

or you can also compile it into a binary by doing this:

bok hello.bok -o hello

then run the binary hello that is created:

./hello

Voila! you have run your first program written in bedrock

Let's briefly breakdown what's happening in this program, then go into more detail throughout the remainder of the tutorial.

The first line declares the printf function from the C ABI using Bedrock's foreign function interface (FFI), allowing the program to link against libc.

The program's entry point is main which executes after program environment is initialized. The shape of this function is defined by bedrock's standard proc which returns no values, it's like a void function.

The purpose of this function for this demonstration is just printing Hello, World! to the console.

Bedrock Basics

Bedrock's syntax might be of some familiarity to people who have used pascal or freebasic like languages. The control flow in bedrock is divided into distinct blocks which starts with respective keyword and ends with the keyword end.

This makes bedrock programs to be read procedurally like a documentation.

let's get started!

Comments

Single line comments in bedrock starts with //

// this is a comment

there are no block comments as of now in bedrock
refer to this discussion if you are curious why
but we are not rigid, so it could be there in future.

Reserved Words

A good way to get a bird eye view of a language's style is to see what words it reserves.
Here's what bedrock has:

import    pub     inline  func    proc    extern
type      struct  enum    static  const   var
defer     unsafe  if      elif    else    for
in        while   match   case    return  orelse
comptime  try     end     true    false   break
continue  nil     where   new     ptr     undefined

Identifiers

The naming of variables/identifiers are similiar to other programming languages. Identifiers start with a letter or underscore and may contain letters, digits, and underscores. Case is sensitive.

hi
openSource
NiklausWirth
bjarne_stroustrup
_dandalion
h2g2

In bedrock a new identifiers is assigned using var or const keyword. Here identifiers assigned using var are mutable by default and variables assigned with const are non-mutable, bedrock overall has this property that it's mutable by default.

var a = 5;
var b = 5.42;

here the type of a and b will be inferred, so it's not dynamic typing.

You can declare variables with explicit types.

Like this:

var a: i32 = 5;
var b: f32 = 5.42;
var c: str = "hello sir";

here the types are explicitly declared in syntax.

Type Declarations

All user defined types begin with the type keyword.

• Define a struct in bedrock

type Person = struct
  name: str,
  age: u32,
end

Structs are constructed using where keyword

func main() -> i32
  var p1 = Point where name = "Alice", age = 20 end
  return 0;
end

when using where initializing all values is necessary and if not then you will encounter a semantic error for safety purposes.

• Define an enum in bedrock (todo)

type Color = enum
  red,
  yellow,
  green,
end

• Aliasing in bedrock

it's like #define or type aliasing in go.

type real = f32;
type vecstring = [_]str;

note: when type used for aliasing then end keyword is not used, instead ; is used to end it. As it's not starting a block and just ending in one line, unlike struct and enum (special types). see discussion if you are more curious as to why.

Newlines

A bedrock program could completely be written in a single line, though new lines should be used for convinience and better readability

Blocks

Bedrock does not uses curly braces to define blocks, but uses explicit end keyword where a block ends. A block is everywhere inside of which a statement is allowed, like in control flow statements, expressions, etc.

Ex:

if (eyes_open && morning)
    rise.shine();
else
    print("sleepy");
end

so here if-else is a block and you end it with the end keyword

If you forget to put end at the end of a block, then it's a hard error as block is not closed and could lead to unwanted behaviour of your program.

proc foo()
    // do some crazy work...
end

this is also a block (a procedure block (more about it soon)) that does something crazy.

It's not necessary to have these blocks on different lines like, literally a block, u can have it like this too:

if (is_even(n)) result = true; else result = false; end

Booleans

A boolean represent truth or falsehood, bedrock have two literals for boolean, true and false. Their type is bool.

Numbers

Bedrock is a systems programming language so it has many built in strict types.

• numerical literals

0
42
-3.14
0xc1c1c1
10_21_201

• numerical types

u8
i8
u16
i16
u32
i32
u64
i64
usize (u64)
isize (i64)
f32 (float)
f64 (double)

Strings

A string is array of bytes, in bedrock strings are not null terminated and are represented like this { ptr: *T, len: usize }, a fat pointer and the length, and for use with c ABI, it could be converted to a null terminated string. (todo)

• String literals are surround in double quotes:

"bok bok"

• Type of string is str in bedrock

• Escaping

These escape characters are supported.

"\n" // Newline.
"\t" // Tab.
"\r" // Carriage return.
"\x00"
"\\" // A backslash.
"\"" // A double quote character.
"\a" // Alarm beep. (Who uses this?)
"\b" // Backspace.
"\f" // Formfeed.
"\v" // Vertical tab.

Char

A char is simply of 8 bit so a char is just u8, but bedrock explicitly also has a type char (u8 only) for chars, for convinience and better semantics.

Ranges

A range is a little object that represents consecutive range of numbers. In bedrock you can represent a range using .. for exclusive range and ..= for inclusive range.

So for example:

for i in 0..10
    // print i
end

will print numbers from 0 to 9. Whereas,

for i in 0..=10
    // print i
end

will print number from 0 to 10.

Nil

Bedrock has special keyword nil which allows many things like if optional variable is not containing any value, then it returns nil.

Arrays

Array are data structures that stores homogenous type of elements in them.

In bedrock array are initialized like this:

var arr: [10]i32 = [];

this initializes an empty array of capacity 10.

You can use _ for inferencing an array's size, it could be used in such manner:

var arr: [_]i32 = [1,2,3,4,5];

Then array will be of capacity 5.

Having such inferencing power allows us for quick declaration of variables, for example you can initialize the above array in short hand like this too:

var arr = [1,2,3,4,5];

But this:

var arr = [];

or this:

var arr:[_]i32 = [];

will result into an obvious semantic error -> cannot infer type or size of empty array literal

What's inferabble is inferabble what's not inferabble cannot be inferred.

Accessing elements

elements of an array are accessed like most other languages, using a [].

proc main()
  var arr = [1,2,3,4,5];
  const c = arr[2];
  printf("%d\n", c);
end

output: 3

Lists are also mutable

proc main()
  var arr = [1,2,3,4,5];
  arr[2] = 10;
  const c = arr[2];
  printf("%d\n", c);
end

output: 10

Slices

Just like array type bedrock has a slice type for passing arrays to functions or using it in some other way like initializing in structs (todo).

func foo(arr: []i32) -> i32
    return arr[2];
end

Here arr is passed to the function foo, and it does not requires any value or _ as it just represents the type of an array.

Procedures and Functions

Bedrock has a clear seperation between a procedure (instantiated by keyword proc) and function (instantiated by keyword func)

proc

A procedure performs work but does not return a value.

proc main()
    for i in 0..100
        printf("%d\n", i);
    end
end

If proc returns something then a strict semantic error is given by the compiler.

Such as this will result in error:

proc main()
  for i in 0..100
    printf("%d\n", i);
  end
  return 1;
end

error: proc cannot return a value

Whereas a bare return in proc works for early return in some branches.

proc main()
  var a = 10;
  if (a > 10)
    return;
  else
    a = 20;
end

func

A function should always return a value

func add(x: i32, y: i32) -> i32
  return x + y;
end

func main() -> i32
  return add(10, 10);
end

A function not returning a value will be warned to the user by compiler.

func add(x: i32, y: i32) -> i32
  var a = x + y;
end

warning: control reaches the end of the function

---

This was an intentional and a well thought distinction between proc and func it improves readablity as now just by seeing proc you know they are not returning anything and also for func we do explicit return type checking but for proc it's not at all necessary proved in obvious way that it does not return any value at all.

This also syncs well with the language's procedural roots.

Control Flow

In bedrock control flow constructs includes and are not limited to if, match, while, for.

--- If Statement ---

If is used for conditional statement control flow.

used solo:

if (is_valid) doit(); end

Use with else

if (is_valid) doit(); else dont(); end

if-elif ladder

proc main()
  var a = 10;
  if (a == 1)
    printf("1\n");
  elif (a == 2)
    printf("2\n");
  elif (a == 3)
    printf("3\n");
end

if-elif-else ladder

proc main()
  var a = 10;
  if (a == 1)
    printf("1\n");
  elif (a == 2)
    printf("2\n");
  elif (a == 3)
    printf("3\n");
  else
    printf("neo\n");
end

output: neo

--- Match-Case (todo) ---

The match-case statements are the switch-case of bedrock.

You can use it for char, number, enums. The especiality of match-case is that it evaluates at compile time so using them makes runtime faster.

Like using match for enums.

match Color
    case red
        printf("red\n");
    case yellow
        printf("yellow\n");
    case green
        printf("green\n");
end

Here if enum Color have more elements in it then just red, yellow and green then semantically it could give warning that not all variants were considered in the match-case.

For such situation to handle the default case we have the else in match:

match Color
    case red
        printf("red\n");
    case yellow
        printf("yellow\n");
    case green
        printf("green\n");
    else
        printf("no color\n");
end

--- While Loop ---

The While loop works in same style, by instatiating a while block ending with end.

proc main()
  var i = 0;
  while i < 5
    printf("%d\n", i);
    i+=1;
  end
end

output:
0
1
2
3
4

--- For Loop ---

The For loop works in same style, by instatiating a for block ending with end. You specify a binding variable and a range or an iterable structure.

proc main()
  var arr = [10, 21, 42, 5];
  for i in arr
    printf("%d  ", i);
  end
end

output: 10 21 42 5

for ranges too:

proc main()
  for i in 7..10
    printf("%d  ", i);
  end
end

output: 7 8 9

Here in both example the binding variable is i and it iterates over arr or the range.

Optional Values (todo)

So some operations or some containers could have a value or not (maybe). These are optional values. And such operations contain the optinal type.

These are denoted by ? at suffix of them like ?user

Here's a function returning optional value:

func find_user(id: u32) -> ?User

Here the return User structure could have a User struct or nil.

Error Propogation (todo)

The language syntax provides a concise way to propogate errors. An error returning value will have a ! at the end like result! unlike ? which is appended at starting.

func load_config() -> Config!
    var file = try open("config.cfg")
    return try parse(file)
end

• If the operation succeeds, execution continues using the returned value.
• If the operation returns an error, the current function immediately returns that error to its caller.

Modules (todo)

Each bok file is a module and modules are imported using import keyword.

import io;
import math;
import graphics.window;

any function, identifiers, user defined types, marked with pub could be now accessed in the file these modules are imported into.

like:

pub func add(a: i32, b: i32) -> i32
  return a + b
end

So, by default all declarations are private in a module.

Unsafe (wip)

The language is memory safe by default. Memory for language objects is managed automatically through the region model (see: memory model), eliminating the need for manual allocation and deallocation in normal programs.

Certain low level operations, however, cannot be verified or protected by the compiler. These operations must be performed inside an unsafe block.

unsafe
// Unsafe operations
end

An unsafe block explicitly indicates that the programmer is taking responsibility for the correctness of the enclosed code.

The presence of an unsafe block serves two purposes:

• It enables low level operations that are otherwise prohibited.
• It clearly communicates to readers that this section of code requires additional care and review.

Operations permitted within an unsafe block include:

• Manual memory allocation and deallocation.
• Raw pointer dereferencing.
• Pointer arithmetic.
• Calling foreign (C) functions.
• Accessing memory mapped hardware.
• Low level memory manipulation.
• Inline assembly (near future).

Example:

extern func malloc(size: usize) -> *u8
extern proc free(ptr: *u8)

unsafe
  var buffer = malloc(4096)
  *(buffer + 8) = 42
  free(buffer)
end

Memory Model (wip)

Region Based

Bedrock uses regions to manage memory, every objects is being allocated in a region and it is reclaimed from all of the region at once when the region goes out of scope intead of keep tracking each allocation.

Invariants about region model

• Every allocation belongs to one region, all allocations within an arena are reclaimed together when that region is destroyed.
• A reference cannot outlive its target, program cannot contain dangling references.
• Destruction happens exactly once when the region goes out of scope.

The compiler tracks the lifetime of references to make sure that a reference cannot outlive the region it currently lives in.

func ret_person() -> &Person
  region R
    var p = Person where id = 0, age = 24 end
    return &p;
  end
end

The compiler can determine that lifetime of return = caller and lifetime of p in region R ends before caller uses the return reference, preventing dangling reference at compile time. User is not explicitly required to annotate the region R in the above example the compiler can infer the lifetime in a function body.

Lifetime concepts

Lexical Region

A lexical region corresponds to a local scope.

proc lexical()
  region @outer
    var p1: &Person
    region @inner
      var p2 = Person where name = "Alice", age = 24 end
    p1 = &p2
    end
  end
end

Here both p1 and p2 are in lexical region, lifetime(p2) < lifetime(p1) so p1 cannot reference to p2. Its not necessary to type the region block manually the compiler can infer the region annotations in this case.

Function params

Parameters are not a separate storage region. A reference parameter borrows an allocation from the caller.

proc set_friend(p: &Person, friend: &Person)
  p.friend = friend
end

Because friend might have a shorter lifetime than p, we need some lifetime annotation hints here.

proc set_friend(p: &@p Person, friend: &@r Person)[@p <= @r]
  p.friend = friend
end

Return

A function cannot return a reference to storage whose lifetime ends before the caller can use the return value. Local references cannot escape their lexical region. We cannot return a reference to local variable to the caller that will result in dangling pointer.

func foo() -> &Person
  var p = Person where name = "Alice", age = 24 end
  return &p
end

Static region

Static storage lives for the entire program.

var local = new(@static) Person where name = "Alice", age = 24 end

Foreign Function Interface

The language provides direct interoperability with C through the native ABI.

extern proc printf(fmt: *u8)
extern func malloc(size: usize) -> *u8

or using variadic

extern proc printf(...)
extern func malloc(...) -> *u8

This allows seamless integration with existing operating system APIs and C/C++ libraries.

See the example using raylib:

extern proc InitWindow(...);
extern func WindowShouldClose() -> bool;
extern proc BeginDrawing();
extern proc EndDrawing();
extern proc CloseWindow();
extern proc ClearBackground(...);
extern proc DrawRectangle(...);

func main() -> i32
  var white: i64 = 245 | (245 << 8) | (245 << 16) | (255 << 24);
  var skin: i64 = 224 | (180 << 8) | (135 << 16) | (255 << 24);
  var nose: i64 = 188 | (142 << 8) | (106 << 16) | (255 << 24);
  var robe: i64 = 89 | (122 << 8) | (66 << 16) | (255 << 24);
  var robe_dark: i64 = 63 | (88 << 8) | (47 << 16) | (255 << 24);
  var black: i64 = 10 | (10 << 8) | (10 << 16) | (255 << 24);

  InitWindow(800, 600, "Minecraft Villager");
  while !WindowShouldClose()
    BeginDrawing();
    ClearBackground(white);

    // Arms
    DrawRectangle(290, 210, 35, 150, robe);
    DrawRectangle(475, 210, 35, 150, robe);

    // Body / robe
    DrawRectangle(320, 200, 160, 220, robe);
    DrawRectangle(320, 340, 160, 30, robe_dark);

    // Head
    DrawRectangle(340, 90, 120, 110, skin);

    // Eyebrows (villagers have a monobrow-style look per eye)
    DrawRectangle(355, 130, 25, 8, black);
    DrawRectangle(420, 130, 25, 8, black);

    // Big nose
    DrawRectangle(380, 138, 40, 55, nose);

    EndDrawing();
  end

  CloseWindow();
  return 0;
end

output:

---

---

Installation Instructions

For now the preferred way of installing bedrock until we have our own package manager is to go the bedrock github repo and follow the instructions in the readme and you will have a working binary of bedrock called bok.
